Green Pin® Ağır Yük Kilitleri

Green Pin® Standard Shackles

dee shackles with screw collar pin

Material : bow and pin high tensile steel, Grade 6, quenched and tempered
Safety Factor : MBL equals 6 x WLL
Standard : EN 13889, ASME B30.26 and meets performance requirements of US Fed. Spec. RR-Type IVB Class 3, Grade A
Finish : hot dipped galvanized
Temperature Range : -40°C up to +200°C

Certification

2.1

2.2

3.1

MTC a

DNV 2.7-1 a

DNV 2.7-1 b

DNV 2.22

CE

working load limit	diameter bow	diameter pin	diameter eye	width eye	width inside	length inside		length	length bolt	weight each
t	a	b	c	d	e	f	g		h	kg
t	mm	mm	mm	mm	mm	mm		mm	mm	kg
0.33	5	6	12	5	9.5	19		33	29.5	0.02
0.5	7	8	16.5	7	12	22		41.5	38	0.05
0.75	9	10	20	9	13.5	26		50	46.5	0.09
1	10	11	22.5	10	17	32		59	54	0.14
1.5	11	13	26.5	11	19	37		68	59.5	0.19
2	13.5	16	34	13	22	43		81	73	0.32
3.25	16	19	40	16	27	51		97	89	0.54
4.75	19	22	46	19	31	59		112	103	0.87
6.5	22	25	52	22	36	73		134	119	1.34
8.5	25	28	59	25	43	85		154	137	2.08
9.5	28	32	66	28	47	90		167	153	2.77
12	32	35	72	32	51	94		180	170	3.72
13.5	35	38	80	35	57	115		209	186	5.14
17	38	42	88	38	60	127		230	203	6.85
25	45	50	103	45	74	149		271	243	11.45
35	50	57	111	50	83	171		305	272	16.86
42.5	57	65	130	57	95	190		345	310	24.61
55	65	70	145	65	105	203		376	344	32.65
